Instrument Cluster 540/1000 PTO Operation Speed This indicator shows 540/1000 PTO operation speed.
540E PTO Operation Speed This indicator shows 540E PTO operation speed. This symbol will glow if the feature is equipped.
Trip Hour Counter This is a LCD hour counter located under the tachometer. It is operated when the engine is running. Trip hour counter displays the running hours for the particular trip. The run hour is calculated in real time, i.e. 60 minutes of tractor run is calculated as 1 hour only. After 999.9 hours is completed, the count restarts from zero. The blinking of the symbol indicates that the run time is counted on real time.
Trip Hour Reset Button This is located on cluster bezel and is used to reset the trip hour meter as and when required. This can be done by continuously pressing the button more than 2 seconds.
Beeper Output Provision The Beeper will beep at different rate during following conditions. Priority
40
Description
Beeps/min
1
High Coolant Temperature
60
2
Engine Low Oil Pressure
50
3
Transmission Oil Pressure
40
4
Battery Charging Indicator
30
5
Air Filter Clog
10
6
Service Reminder
30
8000 Series, Models - 8090/8100 4WD CAB TIER-4 Final
