Instrument Cluster 17
18
16 15
19
14
20
13
21
12
22
11
23
10
24
9
25
8
26
7
27
6
28
5
29
4
30
3
31 32
2
33 1
34
Instrument Cluster The Instrument Cluster is a descriptive unit that gives the user various indications about the working of the tractor and its various features. It consists of the following. 1. Tractor Run Hour Counter 2. DEF Level Indicator 3. Service Reminder Indicator 4. Water In Fuel Indicator 5. 540 RPM PTO Indicator 6. Air Filter Clogging Indicator 7. F-R Shuttle Switch Neutral Indicator 8. Air Pre-Heat Indicator 9. Fuel Level Gauge 10. Clutch Over Ride Indicator 11. High Beam Indicator 12. PTO Engaged Indicator 13. LH Turn Indicator 14. MIL Indicator 15. High Temperature Warning Indicator 16. 540E PTO Operation Speed 17. Low Fuel Indicator 18. Tachometer (RPM Meter) 34
19. Low Oil Pressure Indicator 20. Battery Charging Indicator 21. RH Turn Indicator 22. SCR Tampering Indicator 23. Parking Brake Indicator 24. Diesel Exhaust Fluid (DEF) Quality and Low Level Indicator 25. Coolant Temperature Gauge 26. Engine Stop Indicator 27. 4WD Indicator 28. Exhaust Temperature Indicator 29. 1000 RPM PTO Indicator 30. Diesel Particulate Filter Indicator 31. Transmission Oil Pressure Indicator 32. Check Engine Indicator 33. 540/1000 PTO Operation Speed 34. Trip Hour Counter 8000 Series, Models - 8090/8100 4WD CAB TIER-4 Final
