Hydraulics & Transmission Hydraulic Suction Filter (A) Change Hydraulic suction filter initially at 50 hrs. and subsequently at every 400 hrs. of operation. This Spin-on type filters is located behind the DEF Tank on RH side of tractor. Remove old spin-on filters. Prime the new spin-on filter with clean oil and fit them. NOTE: The hydraulic suction filter though resembles with engine oil filter, it differs in construction and usage. Hence these are not interchangeable.
A
Hydraulic Strainer (B) Clean the suction strainer during every oil change. The Suction strainer is located on RH Side of rear housing. For Service / Replacement of strainer, contact your Mahindra Dealer.
B
Transmission Strainer (C) Clean the suction strainer during every oil change. The Suction strainer is located on RH Side of speed housing.
C
For Service / Replacement of strainer, contact your Mahindra Dealer.
Transmission Oil Drain Three drain plugs ( D to F ) are provided on the transmission for draining transmission oil. The drain plug (E) located on the dropbox is at the lowest position. D
E
F
Bottom view 110
8000 Series, Models - 8090/8100 4WD CAB TIER-4 Final
