3.4.7
Joystick functions Caution! The machine is delivered as standard with normal control. On request, the machine can be equipped with a control system that deviates from the norm (eg. with LIEBHERR control). The additional operating instructions for this control system apply in this case. The joystick functions described here refer exclusively to normal control. Activate stanchion: The stanchion cylinder is operated using the left joystick 4.
Fig. 3-50
Activate stanchion:
Push the joystick back a. Stanchion will be retracted. Push the joystick forwards b. Stanchion will be extended. Activate the adjustable boom: The boom is operated using the right joystick 3.
Fig. 3-51
Activate the adjustable boom:
Push the joystick back g. Equipment will be raised. Push the joystick forwards h. Equipment will be lowered.
