Control, operation
Operating instructions
Operation
3.3.2.4
Throttle control
Fig. 3-35
Throttle control
The throttle control R75 permits continuous adjustment of the engine RPM over the full RPM range.
3.3.2.5
Engine overheating If the engine overheats, the indicator light H175 lights up and a warning signal (buzzer) sounds simultaneously. Shut down the Diesel engine immediately (see also the Deutz engine operating and maintenance manual).
Fig. 3-36
Diesel engine air intake
Note! To ensure optimum conditions for the engine, remove any ice and snow from the engine hood in the area of the cooling and combustion air intake before starting the Diesel engine.
3.3.2.6
Notes after starting the engine Danger! Danger of suffocation. When operating in closed spaces, run the engine only with sufficient ventilation. Open doors and windows to ensure sufficient supply of fresh air.
3 - 36
MJFCIFSS
A 316 Litronic Industrie / 8720370
