Control, operation
Operating instructions
Operation
Cab roof Pull out the sun visor and secure it in the retainers designed for this purpose. To retract the sun visor, remove it from the retainers and let it roll up slowly.
3.2.9
Emergency exit – rear window
Fig. 3-23
Emergency exit – rear window
By pulling the bracket 1 on the inside of the rear window, the rubber weather strip 2 can be released and removed. In case of an emergency, pull off the rubber weather strip 2 from the circumference of the window and push the window out.
3.2.10
Interior illumination
Fig. 3-24
Interior illumination
The interior lighting is turned on with the slide regulator 1. Push the slide regulator to the right. Light 2 is turned on. Push the slide regulator to the left. The spot light 3 is turned on. Push the sliding regulator to the center position. The interior illumination is turned off.
3 - 24
MJFCIFSS
A 316 Litronic Industrie / 8720370
