Control, operation
Operating instructions
Operation
3.2.5.3
Adjusting the horizontal seat position
Fig. 3-16
Horizontal seat adjustment
Pull up the lever 1 to push the operator's seat in the horizontal direction. Pull up the lever 2 to push the operator's seat including the control panels in the horizontal direction.
3.2.5.4
Adjusting the seat suspension
Fig. 3-17
Adjusting the seat suspension
Use the turning knob 5 to adjust the seat suspension to match the body weight.
3 - 20
MJFCIFSS
A 316 Litronic Industrie / 8720370
