Control, operation
Operating instructions
Operation
To unlock the door lock: The door is secured in lock 2. Move lever 4 next to the cab frame outwards. The door is now unlocked. Close the doors.
3.2.2
Adjusting the cab The height of the cab is fully adjustable. Danger! There is a risk of accident and injury with a raised cab if the route is not clear of obstacles or has a gradient. The stability of the machine could be affected. Do not drive the machine with a raised cab if there are obstacles or gradients on the route. Only adjust the cab when the machine is stationary. Ensure there are no persons within the danger zone around the machine when carrying out cab adjustments.
Fig. 3-10
Adjusting the height of the cab
Raise the cab using control lever 12. The machine is ready for operation. The safety lever is pushed down. The engine is running. Switch on servo control S35. Push control lever 12 backwards a. The cab moves upwards as long as the control lever is being pressed. Push control lever 12 forwards b. The cab moves downwards as long as the control lever is being pressed.
3 - 16
MJFCIFSS
A 316 Litronic Industrie / 8720370
