Control, operation
Operating instructions
Operating and control elements
S46 - Magnetic system* Press switch down. Magnetic system is activated. Indicator light in the switch illuminates. Press switch up. Magnetic system is deactivated. Indicator light in the switch goes out. S47 – Hydraulic quick-change adapter* Press and hold button down. The hydraulic quick-change adapter is activated. Indicator light in the switch illuminates. Release the button. The hydraulic quick-change adapter is deactivated. Indicator light in the switch goes out. S61 – Driving light This switch has three settings: Neutral (0), Position 1 and 2. Push the switch down to position 1 (centre position). Sidelight is activated. Push the switch down to position 2 (final position). Driving light is activated. The switch can also function if the ignition key is in position 0 or P. S204 - S207 – Individual control, claws* Press the switch. The corresponding outrigger is activated. Indicator light in the switch illuminates. Press switch again. The corresponding outrigger is deactivated. Indicator light in the switch goes out. S216 -- Bypassing stanchion cylinder shut-down* Press and hold button down. Stanchion cylinder shut-down is bypassed. Indicator light in the switch illuminates. Release the button. Stanchion cylinder shut-down returns to its original function. Indicator light in the switch goes out. S218 – Windscreen wiper on cab roof (green) This switch has three settings: Neutral (0), Position 1 and 2. Push the switch down to position 1 (centre position). Continuous operation is activated. Push the switch down to position 2 and hold (final position). Washing water will be sprayed on the windscreen. The windscreen washer runs continuously.
3 - 12
MJFCIFSS
A 316 Litronic Industrie / 8720370
