Control, operation
Operating instructions
Operating and control elements
H13 – Air filter contamination (orange) If the air filter is heavily contaminated, the indicator light illuminates. Bring the diesel engine to low idle immediately. Allow the engine to idle for approximately 5 seconds. Shut down the diesel engine. If necessary, replace the filter element. H15 – Hydraulic oil temperature (red) The indicator light illuminates if the hydraulic oil temperature in the tank exceeds 98 °C. Bring the diesel engine to low idle immediately. Shut down the desel engine as quickly as possible. Locate and rectify the error (radiator dirty etc.). H16 - overload warning (red)* The indicator light illuminates if the maximum permissible load carrying capacity of the machine is reached and the overload warning device S18 is switched on. The buzzer in the cab sounds simultaneously. Avoid increasing the load any further. Reduce the load on the machine. H18 – coolant level low (red) The indicator light illuminates if the coolant level drops below a specified level. Bring the diesel engine to low idle immediately. Shut down the diesel engine as quickly as possible. Locate the leak and carry out repairs. Caution! This monitoring device acts as an increased level of security in case of larger amounts of water loss (e.g. hose rupture). It does not relieve the operator or maintenance personnel from the responsibility of regularly checking the coolant level in the equalizing reservoir. H19 - indicator The indicator light illuminates after the direction indicator turn signal switch has been operated and when the hazard warning system is operating. H20 - Parking brake The indicator light illuminates if the parking brake is engaged (S16) or if the parking brake's release pressure is too low.
3-8
MJFCIFSS
A 316 Litronic Industrie / 8720370
