Control, operation
Operating instructions
Transport
Press switch S16 down. Parking brake is engaged. Indicator light in the switch illuminates. Switch off the engine, push the safety lever up. Secure the superstructure on the chassis using the pillow block. Push the safety lever down. Turn the ignition key to the contact position and relieve pressure lines by moving the joystick carefully several times. Remove the ignition key and push the safety lever up. Close and lock all doors, covers and panels on the machine. Fold in the mirror. To secure the machine: The machine must be secured against slipping before starting the journey.
Fig. 3-94 1
Securing the machine
Dozer blade
2
Claw support
Danger! Serious accidents can occur if the machine is allowed to slip on the loading ramp. Secure the machine against slipping. To do this, use chocks and a tension cable or tension chains. Secure the machine at the points provided for the purpose using tension cables or tension chains. The "anchor points" are identified by an information plate. Secure tension cables and tension chains on the low loader according to type. Transport route: Danger! Driving beneath obstacles which are too low can cause serious accidents. Drive under obstacles, particularly electrical lines, with increased caution.
3 - 94
MJFCIFSS
A 316 Litronic Industrie / 8720370
