Control, operation
Operating instructions
Installation and removal of attachment parts
To lock the quick change adapter: Press switch S19 down. The auxiliary hydraulic device is activated. The indicator light in the switch lights up. Press and hold button S47 down. The quick change adapter is activated. The indicator light in the switch lights up. On the left joystick 4, press and hold the left push button L down until the locking pins are fully extended. The buzzer turns off. The indicator light H26 turns off. The quick change adapter is locked. If properly picked up, the working tool is now connected. Release button S47. The hydraulic quick change adapter is deactivated. The indicator light in the switch turns off. Press switch S19 up. The auxiliary hydraulic device is deactivated. The indicator light in the switch turns off. Caution Hydraulic lines are pressurized! Before connecting the hydraulic lines, release the pressure using the joystick (shut down the Diesel engine, turn the ignition key to the contact position, operate the joystick). Connect hydraulic lines or electrical lines, if necessary. (e.g. for grapple installation). A direct visual check must be made to ensure that the working tool is seated tightly. In addition, a “working cycle” should also be performed with the working tool. This means that the working tool should be raised before use to the point where tight seating of, for . example, the pin in the pin eye, can be checked by curling in and out. Danger! The electronic monitoring system for the quick change adapter displays defective functions. This could be caused by an uncontrolled position change of the locking pins, due to mechanical or hydraulic damage. A defect may also be present in the electrical system (e.g. proximity switch or buzzer). If the buzzer and indicator light are activated without initiation of a deliberate locking or unlocking procedure, stop all work at once. If the buzzer and indicator light are not activated while a deliberate locking or unlocking procedure is being carried out, stop all work at once. Only resume working only after any defective parts have been repaired or replaced. Perform the working cycle. Before starting to use the working tool (e.g. grapple, ditch cleaning bucket), the special installation guidelines in the chapter “Installation and removal of attachment parts” must be observed.
3 - 78
MJFCIFSS
A 316 Litronic Industrie / 8720370
