16. ELECTRICAL EQUIPMENT
I 1. STARTER CABLE
I
2 POWER TILT RELAY
1. STARTER CABLE Type With Power Tilt
a. REMOVAL
[11 STARTER CABLE 1P CONNECTOR
121 POWER TILT RELAY CONNECTOR
1) Remove the following: - engine cover (P. 5-1). - left engine under cover (P. 5-3).
2) Unfasten the wire band, and remove the power tilt relay wire connectors with the connector holder attached from the starter case B. 3) Disconnect the 1P connector and remove the connector from the connector holder. 4) Remove the fuse holder from the fuse holder bracket.
5) Pull the starter cable connectors from the holder on the starter case B, and disconnect the white and white/black wire connectors..
121 STARTER CABLE
STARTER CASE 6
16-1
[
\'
[3] WHITEBLACK WIRE
