Steel Tank
SCREW (4) /
/
/
121 FUEL
REASSEMBLY: Check the float for smooth movement.
/
[6] TUBE CLIP B,.1D I
[12] INLET VALVE [13]FUEL HOSE (SHORT) REASSEMBLY: Check for cracks and deteriorations. Replace if necessary.
[14]TANK CAP
[15]FUEL TANK Clean any dirt or foreign material from the fuel tank strainer, and check for tears in the strainer mesh. ~~~~
6-22
J
._
CAPACITY: 13 2! (3.4 US gal, 2.9 Imp gal) ASSEMBLY: Clean the tank of dirt or dust accumulation, before assembly.
