BI001467
_______________________________________________________ Operation Tramming using the hydraulic control levers 1. Turn the “FWD/OFF/REV” selector switch located on the cover of the starter enclosure to the “OFF” position. 2. Turn the “TRAM/OFF/CONV” selector switch located on the cover of the starter enclosure to the “TRAM” position. 3. Turn the “MAN/OFF/AUTO” selector switch located on the cover of starter enclosure to the “MAN” position. 4. Set main circuit breaker located on the door of the starter enclosure by first moving the circuit breaker lever to the “RESET” position and then to the “ON” position. 5. Push the “ACKNOWLEDGE ALARMS” button once to engage the MCR. Press the button a second time to clear any faults. 6. Engage the “START BREAKER” pushbutton located on the cover of the starter enclosure to start the pump motor. 7. Lift up the neutral start valve handle guard all the way back so that the guard will not fall on the operator’s hands. The machine can now be trammed.
Tramming using the radio remote 1. Turn the “FWD/OFF/REV” selector switch located on the cover of the starter enclosure to the “OFF” position. 2. Turn the “TRAM/OFF/CONV” selector switch located on the cover of the starter enclosure to the “TRAM” position. 3. Turn the “MAN/OFF/AUTO” selector switch located on the cover of starter enclosure to the “OFF” position. 4. Set main circuit breaker located on the door of the starter enclosure by first moving the circuit breaker lever to the “RESET” position and then to the “ON” position. 5. Remove the tram valve handles from the primary valve bank. 6. Position the neutral start guard over the primary valve bank. 7. Push the “ACKNOWLEDGE ALARMS” button once to engage the MCR. Press the button a second time to clear any faults. 8. Move the radio remote “POWER” button to the “ON” position. Listen for 2 beeps. 9. Press the “RESET” button on the radio remote. Listen for 2 beeps. 10. Press and hold the push to operate (deadman) switch on the top of the radio remote. 11. Move the “PUMP START” button on the radio remote to the “START” position. 12. While holding the push to operate switch in, tram the machine using
the left and right “TRAM” switches. ______________________________________________________________ A6474X391 REV 4 5.25
