Replacement of wear parts _________________________________________ Crawler assembly The crawler assembly (Fig. 79) consists of a take-up assembly and drive assembly that transmits torque to the crawler track via a hydraulic drive motor coupled to the tram drive torque hub. As soon as any component of the drive assembly is worn or damaged, the component must be replaced. Fig. 79: Crawler assembly main components
1
2
5
4
3
1. 2. 3. 4. 5.
Crawler track Hydraulic motor (not shown) Torque hub Grease take-up (located behind cover) Take-up roller assembly
