OPERATING INSTRUCTIONS FOUR STABILIZERS VERSION The control of each stabilizer is carried out using the left manipulator.Depending on the button (A) or (B) the left or the right foot are selected with the machine in digging position. The optimal digging position is with the cab turned towards the rigid axle (180° from the normal drive position).
OFF
20
15
10 5
P
25
Km/h
P
30
0
WARNING When the upperstructure is turned 180° the translation and steering controls are reversed. Swinging axle stabilizer cylinders: • Make sure the brake switch (1) is not in parking brake position. • When keeping button (A) pressed, the l.h. control lever is ready to control the l.h. stabilizer cylinder. • When keeping button (B) pressed, the l.h. control lever is ready to control the r.h. stabilizer cylinder. • Operate the control lever forwards (D) to lower the selected stabilizer. • Operate the control lever backwards (C) to raise the selected stabilizer. Fixed axle stabilizer cylinders: • Use the brake switch (1) to select parking brake position. • If keeping button (A) pressed, the l.h. control lever is ready to control l.h. stabilizer cylinder. • If keeping button (B) pressed, the l.h. control lever is ready to control r.h. stabilizer cylinder. • Operate the control lever forwards (D) to lower the selected stabilizer. • Operate the control lever backwards (C) to raise the selected stabilizer.
HORN CONTROL
1
A
B
F8145
C
C
D
D
D
C F12901
NOTE: If keeping button (A) pressed, the l.h. control lever is not ready to control l.h. stabilizer cylinder. if hydraulic speed control lever is in the first (I) speed (lever forwards). NOTE: The l.h. control lever controls l.h. or r.h. stabilizer cylinder if you set the hydralic speed control lever to (II) or (III) speed (lever in central positione or backwards).
1
27401 6-30060 GB
The horn control button (1) is located on the top front of l.h. control lever and allows use during working steps (digging and loading). Press to operate.
F8149
Study SAFETY RULES in the front of this manual thoroughly for the protection of machine and safety of personnel
33
