OPERATING INSTRUCTIONS
LEFT-HAND CONTROL LEVER Dipper cylinder control
A N - Neutral A - Dipper extend B - Dipper retract
N
B
F12829
Upperstructure swing control N - Neutral D - Anticlockwise swing C - Clockwise swing
D
N
C
360°
F12830
Boom pivot cylinder control If keeping button (E) pressed, the left control lever is ready for swing cylinder control.
G
N - Neutral G - Boom counterclockwise swing F - Boom clockwise swing
N
F
27401 6-30060 GB
E
F6107
Study SAFETY RULES in the front of this manual thoroughly for the protection of machine and safety of personnel
30
