MAINTENANCE
AFTER 2500 HOURS OF OPERATION ITEM TO BE CHECKED Hydraulic system oil (*)
Replace
Lubricate
Clean
Check
140 litres
(*) IMPORTANT: if the machine has been filled with biodegradable hydraulic oil PANOLIN AG.-HLP SYNTH 46 (opt), be informed that this oil cannot be mixed with mineral hydraulic oil. Carefully follow the use indications detailed in the section VARIANTS of this manual. In case of doubts, refer to the dealer.
HYDRAULIC SYSTEM OIL (Replacement)
DANGER Do not run the engine in closed spaces without proper ventilation and/or an adequate system capable of removing noxious exhaust gases.
•
•
•
• •
27401 6-30060 GB
•
•
WARNING Never use gasoline, solvents or other flammable fluids to clean parts. Use only proprietary certified solvents which are nonflammable and non-toxic. Hydraulic system components and hoses can reach very high temperatures during operation. Shut-off the machine and wait until it has cooled down before starting inspection or maintenance. Before moving off or operating the attachments, ensure that nobody is within the machine operating range. Before getting on, walk around the machine to inspect it. Sound the horn. Never leave the machine unattended with the engine running Never operate the machine from any position other than from the driver’s seat. Under all circumstances keep all parts of your body inside the operator’s compartment to minimise the risk of exposure to external dangers. Do not work near or under machine attachment if not adequately supported or locked. Fluid under pressure. Always lower the hydraulic attachment to the ground. Stop the engine, press the pressure discharge button located on the hydraulic reservoir prior to starting any maintenance work.
• Park the machine on a level surface and turn the upperstructure 90° to obtain easy access. • Fully retract the dipper cylinder and fully extend bucket cylinder. • Lower the bucket to the ground. • Switch off the auto-idle, fully turn the engine speed manual control anti-clockwise, stop the engine, remove the starter key and move the safety lever into the locked position (LOCK). Wait until the machine is cold. • Apply the maintenance in progress card as shown on chapter “SAFETY SIGNS” to the safety lever.
F5352
Study SAFETY RULES in the front of this manual thoroughly for the protection of machine and safety of personnel
185
