OPERATING INSTRUCTIONS
LOAD HANDLING WARNING The machine has been especially designed for digging/loading works. Handling of loads after finishing the cycle of digging and/or loading work is allowed if the machine is equipped with the special option supplied and installed by CASE personnel. When handling loads, strictly follow national regulations with respect to safety, the rules listed herebelow and those described on chapter SAFETY RULES.
10
15
20 25
5
0
P
Km/h
30
1 WARNING Boom antidrop valves located on cylinders, sound alarm, cab load chart and bucket holes ARE SAFETY DEVICES, belonging to the load handling option. If one of them is missing or damaged, the machine cannot be used for this purpose.
F5355
For handling loads, proceed as follows:
WARNING Before starting to work check the valves for any noticeable damage or abnormal noise. If any, refer to your dealer and, in the meantime, do not use the machine for handling loads. Check if lifting devices (hooks, chains, etc.) are not excessively worn following the rules in force. These lifting devices are not supplied with the machine.
• Set the suitable speed for the hydraulic effort required. • Be informed (if unknown) as to the weight of the object to be handled and compare it with the data shown on the chart in the cab and on page 114. Do not lift loads higher than the maximum values shown on the chart. • Before any lifting operation, press switch (1) to connect a tipping sensor. This sensor activates the sound alarm signal when reaching safety limit load.
27401 6-30060 GB
WARNING To avoid accidents, do not exceed machine load rated capacity. If the machine is not on level ground, load capacities are reduced. Operate with care.
• If available, lower stabilizers or blade to the ground to increase machine stability.
Study SAFETY RULES in the front of this manual thoroughly for the protection of machine and safety of personnel
111
