OPERATING INSTRUCTIONS
PARKING THE MACHINE Drive the machine to firm and if possible level ground. Lower the bucket to the ground. Turn off the A/I mode, if engaged, by pressing the associated control button. Stop the engine following the procedure detailed in the paragraph “USING THE MACHINE” in this Chapter. Move the starter switch key to the OFF position and remove the key. . Set brake switch to position Pull the safety lever upwards and ensure it has reached end of travel in the vertical lock position. Close all windows. Lock the cab door and the following panels: • battery compartment and air filter access panel, • hydraulic pump compartment panel, • tool compartment panel, • engine hood.
CAUTION Do not park the machine on slopes whenever possible.
F6288
Should parking the machine on a slope be unavoidable, proceed as instrument above and observe the following: • Thrust the bucket teeth into the ground. • Adequately block both wheels using wedges, as shown in the figure.
27401 6-30060 GB
IMPORTANT: Always protect cab electrical components from bad weather taking care to close all windows, roof window, and the access door.
Study SAFETY RULES in the front of this manual thoroughly for the protection of machine and safety of personnel
103
