OPERATING INSTRUCTIONS
CONTROL LEVERS NOTE: The following descriptions concerning use of the controls are to be intended with the swinging axle in front position relative to the travel direction. The words right, left, front, back, clockwise, and anticlockwise relate to the Operator’s position when properly sitting in the driver’s seat.
1
5
3
CAUTION Prior to any digging operation, get acquainted with the location and function of each control lever as detailed below.
4
7
8
6
2
F12811
DANGER It is forbidden to expose limbs or any part of the body outside the cab windows during work: Danger of severe injuries and even death. 4 1
NOTE: The machine is fitted with a plate showing all functions of control levers and pedals.
3 2
Main controls 1. Dipper extending (forward) 2. Dipper retracting(reverse) 3. Swing right 4. Swing left 5. Boom lower 6. Boom raise 7. Bucket closing 8. Bucket opening
F6286
When a control lever is released, it returns automatically to the neutral position and the associated work function stops.
6 8 7 5
Study SAFETY RULES in the front of this manual thoroughly for the protection of machine and safety of personnel
96
F6287
27401 6-30060 GB
CAUTION If the machine is fitted with the following options: articulated boom, offset boom, stabilizers/blade, clamshell bucket or breaker, see descriptions of the associated controls in the paragraph “INSTRUMENTS AND CONTROLS” in this Chapter.
