OPERATING INSTRUCTIONS
SAFETY LEVER 1
The safety lever (1) is used to disable swing controls and the attachment movements. It has two positions: • When in the LOCK position (2) with the machine stationary and the engine running or stopped, it prevents the possibility of machine unexpected movements if travel pedal and control levers are accidentally moved. • When in the UNLOCK position, the safety lever enables operation of all controls. Therefore, to control and operate the machine, the lever should be moved to this position.
F5866
WARNING Before starting the engine, ensure that the safety lever is in the LOCK position (vertical).
Lock position
WARNING When the machine is parked or upon leaving it for whatever reason, always ensure that the safety lever in the LOCK position (vertical).
1
Before start-up Before starting the engine, ensure that: • the safety lever (1) is at end of travel in the LOCK position. • switch (1) is in position light (2) on.
, with relative warning F5865
Unlock position After start-up
27401 6-30060 GB
After starting the engine, ensure that the travel controls and control levers are in the neutral position. Lower the safety lever (1) to the UNLOCK position to enable operation of cab controls.
WARNING If attachment movement is detected when the safety lever is released with the control levers still in the neutral position, proceed as follows: • Pull the safety lever to stroke end in the lock position (vertical) • Stop the engine • Contact the nearest Dealer.
1
2
OFF
15
20
10 5
25
Km/h
P
P
30
0
2
1
F6007
Study SAFETY RULES in the front of this manual thoroughly for the protection of machine and safety of personnel
