OPERATING INSTRUCTIONS
STARTING THE ENGINE USING BOOSTER BATTERIES
WARNING Explosive gas is produced while batteries are in use or being charged. Keep naked lights and/or sparks away from the battery charging area. Charge the batteries in a well ventilated place. Park the machine on a dry firm, surface. Do not park on metal surfaces. Take care to make correct connections: never connect a positive terminal ( + ) to a negative terminal ( - ).
F1464
IMPORTANT: The machine electrical system is 24V with negative ( - ) ground. Use only booster batteries with the same voltage.
1
Connecting booster batteries Proceed in the following order: • Connect one terminal of the red cable (1) to the positive ( + ) pole of machine batteries and the other terminal of same cable to the positive ( + ) pole of booster batteries.
Batterie batteries ausiliarie Booster • Connect one terminal of the black cable (2) to the negative ( - ) pole of booster batteries and the other terminal of same cable to ground (machine frame).
2
Batteriebatteries di servizio Service
Massa telaio macchina Machine frame ground F5625
• Start the engine.
Disconnecting booster batteries Proceed in the following order: • Disconnect the black cable (2) terminal from ground (machine frame), then disconnect the other terminal of same cable from the negative ( - ) pole of booster batteries.
27401 6-30060 GB
• Disconnect the red cable (1) terminal from the positive ( + ) pole of booster batteries, then disconnect the other terminal of same cable from the positive ( + ) pole of machine batteries.
Study SAFETY RULES in the front of this manual thoroughly for the protection of machine and safety of personnel
78
