OPERATING INSTRUCTIONS
REFUELLING 1
WARNING Fuel is flammable. Do not puncture or burn containers. Strictly observe the Manufacturer's instructions as regards storage and distribution. Due to the presence of highly flammable vapours, extinguish all smoking materials and open flames or sparks before checking fuel level or refuelling, replacing the filters or opening the condensation drain plug. Do not refuel with the engine running. Do not use matches, cigar lighters or torches as light sources on the machine.
NOTE: Refuel using decanted fuel. Transfer fuel from the storage container to the machine tank using the electrical pump (supplied on request). We advise to fill the tank at the end of the working day to prevent condensation formation overnight. Do not run out of fuel in the tank as this would cause air to enter the fuel system. The fuel system should then be bled from air.
F12671
• Open the filling neck (2) using the key supplied and refuel. • Fuel increasing level makes visible dipstick (3) connected with the float in the tank. • Refill with fuel up to the yellow mark (shown by the arrow) on dipstick (3).
27401 6-30060 GB
3
F8371
Study SAFETY RULES in the front of this manual thoroughly for the protection of machine and safety of personnel
72
