OPERATING INSTRUCTIONS
FRONT WINDSCREENS AND WINDOWS Sliding the front windscreen open/closed
To open the windscreen, first release the lock pins (1). Using the handles, slide the windscreen along the guides in the cab frame until the rear retainer locks (2) automatically.
1
1
WARNING Always ensure that the windscreen is safely locked into the rear retainer.
F5897
To close the windscreen, press the rear retainer release button (2). Using the handles, slide the windscreen along the guides in the cab frame until the front lock pins (1) are safely engaged.
CAUTION
Always ensure that the lock pins are securely engaged into the front retainers. 2
F5898
Opening/closing the side windows
1
27401 6-30060 GB
The window is sliding and can be opened acting on unlock device (1). To close, return it to start position until device (1) fits into its seat operating the automatic lock.
F5894
Study SAFETY RULES in the front of this manual thoroughly for the protection of machine and safety of personnel
65
