IMPORTANT:Do not press on components to prevent damage.
Removing the eKey Board 1. See “Removing the Upper Right Saddle” on page 75. 2. Turn the Upper Cover over and remove the FFC.
3. Remove the single screw
Step eKey Board
Chapter 3
Size M2*3 (NL)
Quantity
Screw Type
1
81
