Removing the Left Speaker Module 1. See “Removing the Upper Cover” on page 70. 2. Remove the two securing screws from the left speaker.
Step Left Speaker Module
Size M2.5*4 (NL)
Quantity
Screw Type
2
3. Grasp both ends of the mylar cover and carefully pull back to expose the speaker cable.
4. While holding the cover with one hand, pull back the speaker cable to remove it from the housing well.
