Removing the Optical Drive Module 1. Remove the Battery Pack. See “Removing the Battery Pack” on page 48. 2. Remove the Memory cover. See “Removing the Lower Covers” on page 51. 3. Remove the screw securing the ODD module.
Step ODD Module
Size M2.5*5(NL)
Quantity
Screw Type
1
4. Grasp the front panel of the ODD and pull to remove from the main unit.
