Removing the WLAN Module 1. See “Removing the Battery Pack” on page 48. 2. Remove the WLAN cover. See “Removing the Lower Covers” on page 51. 3. Disconnect the antenna cables from the WLAN board.
4. Move the antenna cables away and remove the two screws on the WLAN board to release the WLAN board.
Step WLAN Module
54
Size M2*3 (NL)
Quantity
Screw Type
2
Chapter 3
