Power The Power screen allows the user to configure CPU and power management options.
Information
Main
PhoenixBIOS Setup Utility Advanced Security Power Boot
Enable ACPI (debug only): High Precision Event Timer
F1 Help ESC Exit
↑↓ Select Item ←→ Select Menu
[Yes[ [Yes]
F5/F6 Change Item Enter SelectXSubmenu
AMD Exit Item Specific Help En/Disable ACPI BIOS (Advance Configuration and Power Interface) Debug only, remove this option for production.
F9 Setup Default F10 Save and Exit
The table below describes the items, menus, and submenus in this screen. Settings in boldface are the default and suggested parameter settings. Parameter
Description
Option
Enable ACPI (debug only)
Enable or disable ACPI BIOS.
Yes or No
High Precision Event Timer
Enable or disable HPET.
Yes or No
Chapter 2
35
