Bottom View
Item
164
Description
Item
Description
PJP1
AC-IN Connector
JSATA2
HDD Connector
JDOCK1
Dock Connector
JMINI2
TV-Tuner Card Connector
JRJ45
RJ45 Connector
JMINI1
Wireless Card Connector
JMXM1
MXM Board Connector
JSATA1
ODD Connector
JCRT1
CRT Connector
JDIMM2
Memory DIMM2 Connector
JHDMI1
HDMI Connector
JDIMM1
Memory DIMM1 Connector
JUSB1
USB Connector
PJP2
Battery Connector
JUSB2
USB Connector
JCPU1
CPU Socket
JLINE1
Line-In Jack
U25
North Bridge
JMIC1
MIC-In Jack
U37
Volume control wheel
JHP1
Head-Phone Connector
IR1
IR receiver
JREAD1
Card Reader Socket
Chapter 5
