Jumper and Connector Locations Top View
Item
Description
Item
Description
JLVDS1
LCD Connector
JP13
FP/B Connector
JP23
Acer backlight Connector
JP27
Sub-Woofer Connector
JP16
Power/B Connector
JP9
USB/B Connector
JP8
TV/B Connector
JP10
Bluetooth Connector
JP21
Fun/B Connector
JMDC1
MDC Connector
JP14
Media/B Connector
JEXP1
Express Card Socket
JP19
Speaker (Left) Connector
JP17
BTN/B Connector
JP20
Speaker (Right) Connector
SW1
Touch pad (right) Button
JP15
Internal Keyboard Connector
SW2
Touch pad (left) Button
JP7
Touch Pad Connector
U10
South Bridge
