Removing the LCD Bezel 1. See “Removing the Battery Pack” on page 48. 2. See “Removing the LCD Module” on page 68. 3. Remove the two upper and two lower bezel screw caps. Remove the four securing screws from the LCD module.
Step LCD Bezel
4.
98
Size M2.5*5 (NL)
Quantity
Screw Type
4
Lift up the bezel, topside first, and remove it from the LCD Module.
Chapter 3
