4.8. OPERATING ATTACHMENTS
WARNING If a control lever is operated while auto idling, the engine speed returns to its original speed. The left/right control levers control the attachments. The left control lever is for arm, swing; the right control lever is for boom and bucket.
THE LEFT LEVER This lever controls swing and arm. N Neutral (upper frame and arm are maintained at rest position.) 1: Arm out 2: Arm out and right swing 3: Right swing 4: Arm in and right swing 5: Arm in 6: Arm in and left swing 7: Left swing 8: Arm out and left swing
THE RIGHT LEVER This lever controls boom and bucket. N: Neutral (boom and bucket are maintained at rest position.) 1: Boom lower 2: Boom lower and bucket out 3: Bucket out 4: Boom raise and bucket out 5: Boom raise 6: Boom raise and bucket in 7: Bucket in 8: Boom lower and bucket in
117
