Active Alarms The Active Alarms screen displays current fault information. When the faulted condition is corrected the message will be removed from this screen and appear in the Fault History. The Active Alarms screen displays a different Button menu across the bottom of the screen. This menu is specific to the Active Alarm display.
• Next Message Moves the selection bar down the screen one fault at a time.
• Previous Message Moves selection bar up the screen one fault at a time. • Page Up Scrolls screen up and sets selection bar at the top of the screen. • Page Down Scrolls screen down and sets selection bar at the top of the screen. • List Start Resets display and selection bar to the first fault in the list. • List End Resets display and the selection bar to the last fault in the list.
• Troubleshoot Current Alarm More information can be obtained about a displayed fault by selecting the fault and pressing the Troubleshooting button. A fault is selected by pressing either the arrow keys on the main menu (Previous Message, Next Message) or by selecting the desired
IGBT Shovel HMI - WINCC Manual
Page 80 V 1.21
