rows ously viewed.
located at the top of the screen will take you back to documents previ-
Fault History The fault History screen displays historical fault information. Faults can be viewed in order of receipt, or sorted by, date, time, or fault type. The fault history screen displays a different Button menu across the bottom of the screen. This menu is specific to the fault display.
• Next Message Moves the selection bar down the screen one fault at a time.
• Previous Message Moves selection bar up the screen one fault at a time. • Page Up Scrolls screen up and sets selection bar at the top of the screen. • Page Down Scrolls screen down and sets selection bar at the top of the screen. • List Start Resets display and selection bar to the first fault in the list. • List End Resets display and the selection bar to the last fault in the list. • Short Time Archive Displays last 250 messages. • Long Time Archive Displays all messages occurring in the last 30 days.
IGBT Shovel HMI - WINCC Manual
Page 76 V 1.21
