Swing Break Valve (Q 17.0) A “1” at this output activates Swing Brake Solenoid Valve and releases brake.
Hoist Brake Solenoid Valve
•
Hoist Drive Minimum Current (DB3410.dbx0.4)
•
Hoist Drive On (To SiBas) (Q 24.1) This is a command bit to SiBas to turn on the Hoist drive.
•
Hoist Brake Valve (Q 16.0) A “1” at this output activates Hoist Brake Solenoid Valve and releases brake.
•
Hoist Speed < 2.5 Hz (DB3410.dbx1.7)
•
Hoist In Regeneration (DB3418.dbx1.1)
•
Hoist Gate Blocked (DB3418.dbx0.0) The Hoist Gate Blocked signal from SiBas indicates either a Hoist drive fault or Hoist drive is not on.
•
Machine Stop Pushbutton (I 33.0)
•
Power Off Emergency Pushbutton (I 33.1) POEB button is a NC switch which is on when no emergency..
