Swing Brake Solenoid Valve
•
Swing Minimum Current (DB3412.dbx0.4)
•
Swing Drive On (To SiBas) (Q 24.2) This is a command bit to SiBas to turn on the Swing drive.
•
Swing Break Valve (Q 17.0) A “1” at this output activates Swing Brake Solenoid Valve and releases brake.
•
Swing Speed < 2.5 Hz (DB3412.dbx1.7)
•
Swing In Regeneration (DB3418.dbx1.3)
•
Swing Gate Blocked (DB3418.dbx0.2) The Swing Gate Blocked signal from SiBas indicates either a Swing drive fault or Swing drive is not on.
•
Machine Stop Pushbutton (I 33.0)
•
Power Off Emergency Pushbutton (I 33.1) POEB button is a NC switch which is on when no emergency.
•
Drives Power Contactor ( I 32.7) DPC signal is an auxiliary contact input of the DPC output contactor. DPC Contactor is the main contactor for power delivery to all Active Front Ends (AFEs) and all drives.
