Pressing a button displaying a double arrowhead will increment the display value by +/- 10 depending on the arrow direction. • Monitor Motion Button Changes screen the Monitor Motion Detail screen. Screen exit is not allowed from the Monitor Motion Screen. To exit this screen return to the Run Manual screen. • Screen Help Button Displays information about all the button functions on this screen. • Exit Manual Mode Button Screen must be exited using this button. This button sets the appropriate exiting conditions. A Please Wait screen will appear until the proper conditions are set for exiting. When exit is available another screen will popup allowing you to exit the screen. Exiting this screen returns the display to Motion/AFE Selection Screen. • •
Exit Conditions • Brakes Set • Drives Off Exit via Exit Manual Mode button only, if the screen is not exited in this manner a warning screen will appear.
Run VHz
IGBT Shovel HMI - WINCC Manual
Page 13 V 1.21
