Run Manual
This screen is password protected and should be entered by trained personnel only. All drives are switched to Manual Mode upon entry into this screen. Entry into this screen is only permitted if all drives are off and all brakes are set. A message will be displayed upon entry into this screen blocking all selections until the change to Manual Mode is complete. If at anytime Manual Mode fails, a screen will display blocking further activity and instructions for logging out of this screen. From this screen you can manually start and stop all swing drives, change speed and current limits, and monitor status and actual values. Monitor Motion screens can be accessed from this screen. To exit this screen all drives must be off and brakes set. Screen must be exited via "Exit Manual Mode" button to insure all conditions have been met. • Entry conditions • Brakes Set • Drives Off • Correct Password •
Screen Options • Brake Mode The Brake Mode section is located in the upper-right hand side of the screen. The AUTO MODE/MANUAL MODE button is a toggle button, which allows the operator to change the brake mode from automatic to manual. The Status display below the button displays the actual brake mode. When the brake is in Automatic mode the status display displays the text AUTO MODE on a green background. When the brake is in Manual mode the text MANUAL MODE is displayed on a flashing red
