Project Installation There are 4 directories of files included on the installation CD. Insert the CD containing the project and through Windows Explorer select the project and copy to the following locations: Shovel_HMI_v4_4_1.exe: This is a self extracting file. When double-clicked, select unzip and it will install into the correct directory. HTMLfiles_xxx.exe
This is a self extracting file. When double-clicked, select unzip and it will install into the correct directory. Select the correct file for the language you want to install.
Textfiles.zip
Project associated files. Copy to C:\Siemens\textfiles.
FaultHistory.zip
Files required for the Fault History backup. C:\Siemens\textfiles.
Copy to
Note: Be sure each directory is transferred to the correct drive as this is critical to the proper operation of the project. Once your project directories are properly copied close Windows Explorer. Go to the Start button on your Windows Taskbar. Select Start Æ Simatic Æ WinCC Æ WinCC 6.0. This will open the WinCC Control Center. Select File Æ Open. WinCC applications are stored in C:\Program Files\Siemens\WinCC\WinCCProjects. Open the project directory and select the file with .MCP extension, double click or select open. Once Control Center is open, you may be asked to “Start server locally”. If so, click this button, wait for WinCC to start completely. Next, shut down WinCC are restart. Your project should be ready to run. Press the arrowhead icon in the Toolbar to start Runtime.
Troubleshooting "Grayed Out" symbols. When the HMI is not communicating properly, status displays and fields will appear "grayed out".
