2022.3-0000010 OM The following total value of electrical power takeoff to supply coupled machines (with engine speed not less than 1 500 rpm) is stipulated by the tractor design: 1. In dark-time with all lighting on: - not more than 30A, with continuous running duty; - not more than 45A, with repeated short-time running duty with running duration below 15% of total time of tractor running; 2. It is assumed to increase the input power to the following values in day-time with lighting off: - not more than 50 , with continuous running duty; - not more than 70A, with repeated short-time running duty with running duration below 15% of total time of tractor running. ATTENTION: THE ELECTRICAL CIRCUIT OF THE COUPLED MACHINE ELETRICAL EQUIPMENT CONNECTED TO THE ALTERNATOR SHALL HAVE FUSES WITH CORRESPONDING RATING!
2.23 Reverse post controls of BELARUS-1822 .3/2022 .3 BELARUS – 1822 .3/2022 .3 is equipped with a reverse control post with the aim to increase opportunities of coupling with front-mounted agricultural machines. Elements of the reverse control are as follows: - reverse motion steering column with a dosing pump and a reverse valve; - duplicated pedal drives to control the coupling clutch, brakes and fuel feed; - seat reversing mechanism; - additional disconnect switch of rear screen wiper, horn button; - annunciator of emergency modes of engine operation (buzzer). ATTENTION: TRACTOR REVERSE CONTROL POST IS INTENDED ONLY FOR AGRICULTURAL OPERATIONS WHEN MOVING BACKWARDS! IT IS FORBIDDEN TO MOVE ON REVERSE ON PUBLIC ROADS, AND ALSO AT WORKS, NOT RELATED TO AGRICULTURAL PRODUCTION! Supplementary controls of the reverse post are mounted at the rear of the cab, their location is shown in figure 2.23.1.
63
