2022.3-0000010 OM 2.19.3 BELARUS seat installation for operation on reverse
on reverse
on forward motion
1 – clamp; 2 – jaw; 3 – handle; 4 – clamp. Figure 2.19.2 – Seat installation for operation on reverse Seat installation for operation on reverse is carried out in the following order: - release clamps 1 (figure 2.19.2) and take them aside, exempting jaws 2 of the upper base of the uplift mechanism; - pulling a handle 3 up, unlatch the rotation mechanism and rotate the seat by 180°; - applying force up and forward, move the seat to the extreme position against the stop; - carry clamps 4 into the jaws 2 and screw them in against the stop; The seat installation for operation on forward motion is carried out in a reverse order. Seat adjustments on reverse are carried out in the same way as on forward motion. 59
