2022.3-0000010 OM 2.17.3 Fuses of electronic control systems To get access to cutout fuses of electronic control systems (ECS) remove a screw 3 (figure 2.17.9) on a cover 2 of the side console 1 and open the cover.
1 – side console; 2 – cover; 3 – screw. Figure 2.17.9 – Access to ECS cutout fuses Fuses of electronic systems controlling DL, FDA, gearbox reduction unit, FPTO (if available) and RLL are provided in figure 2.17.10.
1 – cutout for FDA drive control (7,5 ); 2 – cutout for rear axle DL control (7,5 ); 3 – cutout for FPTO control (7,5 ); 4 – cutout for RLL control (7,5 ); 5 – cutout for gearbox reduction unit control (15 ); 6 – reserve cutout (7,5 ). Figure 2.17.10 – Cutouts for electronic control system
55
