2022.3-0000010 OM 2.17.2 Fuses for electrical equipment system To get access to cutout fuses located in the upper compartment of the cab on the right do a screw 2 out (figure 2.17.1) and remove a cover 3.
1 – deflectors, 2 – screw; 3 – cover, 4 – upper shield unit of button switches. Figure 2.17.1 – Access to cutout fuses located in the upper compartment of the cab The fuses located in the upper compartment of the cab are shown in fig. 2.17.2.
1 – 15A cutout for rear lights (a pair of inner lights); 2 – 7.5A cutout for cab light and “road-train” light (if available); 3 – 7.5A cutout for rear screen washer and wiper; 4 – 15A cutout for front working lights (on the roof); 5 – 25A cutout for rear working lights (a pair of outer lights); 6 – 25A cutout for air conditioner control system;. Figure 2.17.2 – Cutouts, located in the upper compartment of the cab To get access to cutout fuses located under the dashboard, do a screw 2 out (figure 2.17.3) and remove a cover 3.
1 – clutch pedal; 2 – screw; 3 – panel Figure 2.17.3 – Access to cutout fuses located under the dashboard
52
