Removing the Hinge Covers 1. See “Removing the Battery Pack” on page 54. 2. Remove the two screw caps and screws from the Hinge Covers.
Step Hinge Covers
Size M2*3
Quantity
Screw Type
2
3. Slide the covers off the hinges in the direction of the arrows. IMPORTANT:The left and right Hinge Covers are shaped differently and marked L and R on the inside. Ensure that the correct cover is used during reassembly.
