DOS Flash Utility Perform the following steps to use the DOS Flash Utility: 1.
Press F2 during boot to enter the Setup Menu.
2.
Select Boot Menu to modify the boot priority order, for example, if using USB HDD to Update BIOS, move USB HDD to position 1.
Information
Main
InsydeH20 Setup Utility Advanced Security Power Boot
Boot priority order: 1. 2. 3. 4. 5. 6.
IDE0 : ST9160310AS IDE1 : Slimtype DVD A DS8A2S USB FFD : Network Boot : Atheros Boot Agent USB HDD : USB CDROM :
F1 Help ESC Exit 3.
↑↓ Select Item ←→ Select Menu
F5/F6 Change Values Enter Select XSubMenu
Rev 3.5 Exit Item Specific Help Use < ↑ > or < ↓ > to select a device, then press <F5> to move it down the list, or <F6> to move it up the list. Press <Esc> to escape the menu
F9 Setup Default F10 Save and Exit
Execute the IFLASH.BAT batch file to update BIOS.
The flash process begins as shown.
Chapter 2
43
