Boot This menu allows the user to decide the order of boot devices to load the operating system. Bootable devices includes the USB diskette drives, the onboard hard disk drive and the DVD drive in the module bay.
Information
Main
InsydeH20 Setup Utility Advanced Security Power Boot
Boot priority order: 1. 2. 3. 4. 5. 6.
IDE0 : ST9160310AS IDE1 : Slimtype DVD A DS8A2S USB FFD : Network Boot : Atheros Boot Agent USB HDD : USB CDROM :
F1 Help ESC Exit
40
↑↓ Select Item ←→ Select Menu
F5/F6 Change Values Enter Select XSubMenu
Rev 3.5 Exit Item Specific Help Use < ↑ > or < ↓ > to select a device, then press <F5> to move it down the list, or <F6> to move it up the list. Press <Esc> to escape the menu
F9 Setup Default F10 Save and Exit
Chapter 2
