Hardware Specifications and Configurations Processor Item
Specification
CPU Type
Intel Mobile Penryn uPGA, Socket P, 6M L2, FSB 800/1066MHz (see Processor Specification below for more information)
Core Logic
Intel Cantiga GM—for Aspire 4935 (800/1066MHz FSB supported) Intel Cantiga PM—for Aspire 4935G (800/1066MHz FSB supported) ICH9-M
CPU Package
Micro uPGA-478 Package
CPU Core Voltage
Refer to table below
Processor Specifications Processor #
CPU Speed
Cores
Bus Speed
Mfg Tech
Cache Size
Package
Core Voltage
Acer P/N
P9500
2.53 GHz
2
1066 MHz
45 nm
6 MB
uPGA
1.050V 1.162V
KC.95001.DPP
T5800
2.0 GHz
2
800 MHz
45 nm
2 MB
uPGA
1.0375 1.3 V
KC.58001.DTP
T5900
2.2 GHz
2
800 MHz
45 nm
2 MB
uPGA
1.0375 1.3 V
KC.59001.DTP
P8400
2.26 GHz
2
1066 MHz
45 nm
3 MB
uPGA
1.00V1.250V
KC.84001.DPP
P8600
2.4 GHz
2
1066 MHz
45 nm
3 MB
uPGA
1.00V1.250V
KC.86001.DPP
T9400
2.53 GHz
2
1066 MHz
45 nm
6 MB
uPGA
1.050V 1.162V
KC.94001.DTP
T9600
2.8 GHz
2
1066 MHz
45 nm
6 MB
uPGA
1.050V1.162V
KC.96001.DTP
P7350
2.0 GHz
2
1066 MHz
45 nm
3 MB
uPGA
1.00V1.250V
KC.73501.DPP
P7450
2.13 GHz
2
1066 MHz
45 nm
3 MB
uPGA
KC.74501.DPP
T9550
2.66 GHz
2
1066 MHz
45 nm
6 MB
uPGA
KC.95501.DTP
T6400
2.0 GHz
2
800 MHz
45 nm
3 MB
uPGA
KC.64001.DTP
T6600
2.2 GHz
2
800 MHz
45 nm
2 MB
uPGA
KC.66001.DTP
P8700
2.53 GHz
2
1066 MHz
45 nm
3 MB
uPGA
KC.87R01.DPP
P8600
2.4 GHz
2
1066 MHz
45 nm
3 MB
uPGA
1.00V1.250V
KC.86R01.DPP
P8400
2.26 GHz
2
1066 MHz
45 nm
3 MB
uPGA
1.00V1.250V
KC.84R01.DPP
System Board Major Chips Item
18
Specifications
Core logic
Intel Cantiga PM / GM (667/800/1066MHz FSB supported) ICH9-M
VGA
•
NB9MGS-512MB-DDR2
•
Integrated VGA solution for CANTIGA GM / On board VGA card for CANTIGA PM
LAN
ATHEROS AR8121 for Giga LAN
Media Card Reader
JMICRON JMB385
Chapter 1
